Superior quality at a high performance level
This 5 STAR product from "Adam Hall Cables" is a professional cable that delivers exceptional sound quality for the most demanding musicians.
Focusing on musicians who seek the full sound spectrum from their beloved instruments, our team at Palmer® developed this cable with very low resistance and low capacitance, as well as a braided shield that almost 100% avoids magnetic interference. The result of this collaboration between Adam Hall Cables and Palmer® is an unaltered and balanced sound!
To achieve superior quality, we exclusively use original Neutrik® connectors with gold-plated contacts. On the instrument side of the cable, we use the original Neutrik silentPLUG®. It automatically mutes the signal by creating a short circuit during the connection and disconnection process (therefore, do not use silentPLUG® on the amplifier side!). This prevents crackling and noise when changing instruments.
Palmer® products as well as Adam Hall Cables are developed in Germany.
Technical specifications
Technical specifications
- Made in EU
- Engineered in Germany by our Palmer® crew
- Extra large conductor cross-section of 0.50 mm² (AWG20) for max capacitance values
- On the instrument side of the cable we use the original Neutrik silentPLUG®. This prevents noise during the plugging and unplugging process
- No signal transmission interferences thanks to its tin-plated copper braided shielding, with 100% shielding factor
- The original Neutrik® connectors with gold-plated contacts for ensuring long-life plugging cycles
- Conductive PE insulation of 2.40 mm
- Additional protective insulation
- Very robust soft-PVC jacket
General
| Cable length | 6 m |
| Cable jacket | PVC (Polyvinyl chloride) |
| Cable diameter | 7 mm |
| Cable colour | Black |
Plugs
| Connector type plug 1 | 6.3 mm Jack TS |
| Model name plug 1 | Neutrik NP2XX-SILENT |
| Contact material plug 1 | Gold plated |
| Connector type plug 2 | 6.3 mm Jack TS |
| Model name plug 2 | Neutrik NP2X-B |
| Contact material plug 2 | Gold plated |
Line
| Conductor material | OFC (Oxygen-free copper) |
| Conductor cross-section | 1 x 0,50 mm² |
| Capacity/m | 78 pF |
| Conductor impedance/km | 39 Ohm |
| Shielding | Braided copper shielding |
Environmental
| Ambient temperature | -20 - 70 °C |
Dimensions & weight
| Weight | 324 g |
