LD Systems DEEP2 600 Amplifier 2x300W 8 Ohm
The DP600 from LD Systems has Clip Limiter for overload protection, all the connectivity you need, robust steel cabinet, minimal depth of only 35cm and a very clear sound.
LD Systems DEEP2 600 Amplifier 2x300W 8 Ohm
PA POWER AMPLIFIER 2 X 300 W 2 OHMS
The new DEEP2 amp series features four class-H power amplifiers with toroidal core offering amplifying levels from 2 x 400 W till 2 x 810 W at 4 Ohm. During the development of this series we attached a great importance to the reliability and the durability of the amps in continuous operation, this is why we used exclusively high end and selected components for the construction of these products.
The DEEP2 series features a Clip Limiter as well as every common protection circuits. These amps are 2 Ohm and 4 Ohm (bridge) stable in continuous operation. On the rear panel you will find all the common In- and Outputs.
The DEEP2 series will convince every user thanks to a dynamic and very clear sound which is perfectly adapted for Subbass applications as well as for multifunctional speakers. All models are lightweight and feature a robust steel plate housing and a very user friendly and compact design.
The DEEP2 series will prove to be a profitable and reliable choice for bands, renting companies and professional users thanks to its excellent price/performance ratio.
Also known as: DP 600, DP-600
| Product number: | LDDP600 |
|---|---|
| Product type: | power amplifier |
| Type: | 2-channel |
| Rated ouput power (1kHz @ 2 Ohms): | 2 x 300W |
| Rated ouput power (1kHz @ 4 Ohms): | 2 x 400W |
| Rated ouput power (1kHz @ 8 Ohms): | 2 x 300W |
| Rated ouput power (1kHz @ 4 Ohms, bridged): | 600W |
| Rated ouput power (1kHz @ 8 Ohms, bridged): | 800W |
| Output circuitry: | Class H |
| Frequency response: | 20 - 20000Hz |
| THD: | < 0,1 % |
| Signal-to-noise ratio: | 105dB |
| Damping factor: | > 400 |
| Crosstalk: | >80dB |
| Gain: | 35dB |
| Input sensitivity: | 0,75 |
| Protection circuits: | DC protection, clip limiter, thermal overload, short circuit |
| Controls: | 2 x volume, ground lift, mains switch (on/off), bridge/stereo mode selector |
| Display: | Power, limit, protect (protection circuit engaged), level, signal |
| Loudspeaker outputs: | 2 |
| Speaker output connections: | Speakon compatible, Terminal posts |
| Cooling: | highly efficient, automatic |
| Operating voltage: | transformer, 230 V AC / 50-60 Hz |
| Weight: | 12,8kg |
| Features: | Volex mains socket |
