OMNITRONIC EM-550B MK2 Entertainment Mixer

1 5
€304,95
External warehouse – Estimated delivery in 10–14 business days.
Secure checkout
  • Apple Pay
  • Google Pay
  • Klarna
  • Mastercard
  • USDC
  • Visa
4.8 of 5 14,000+ reviews

Others also bought:

Show all OMNITRONIC

Description


Multifunctional 5+2-channel installation mixer, black

  • 5 input channels with recessed gain controls on the rear panel, signal LED and smooth channel faders
  • Prefader listening to input channels and the master output via adjustable headphones output, with cue mix/split function
  • 2 adjustable master outputs with 3-way equalizer and 10-digit stereo LED level meter
  • (19") 48.3 cm rack installation 2 U
  • For application areas such as: Installation; restaurants, bars and hotels; clubs/dancing school


Scope of delivery
  • 1 x mixer
  • 1 x user manual
  • 1 x power cord
  • 1 x RCA cable


Power supply: 230 V AC, 50 Hz
Power consumption: 9 W
Protection class: Protection class II
Power connection: Power supply cord with Euro plug (provided)
Frequency range: 20 - 20000 Hz
S/N ratio: >65 dB line/phono
THD: Line/phono <0.02 % at 1 kHz
Gain: Microphone 52 dB
Line 19 dB
Phono 54 dB
Housing color: Black
Control elements: Power switch, regular talkover, source selector
Status LED: Signal, master level meter, peak, channel source; CUE, talkover, ON AIR, routing
Connections: Input: microphone via 2 x 3-pin XLR/6.35mm jack (F) combination socket (mounting version)
Input: line/phono via 2 x stereo RCA
Input: line via 9 x stereo RCA
Output: master via 2 x 3-pin XLR
Output: master via 2 x stereo RCA
Output: headphones via 1 x 6.3-mm-jack (bal.)
Output: booth via stereo RCA
Output: rec. via 2 x stereo RCA
Channels: Input channel: 2 x stereo with line-line/phono switch via RCA, channel control via fader, , gain control, source selector, CUE switch
Input channel: 3 x stereo with line-line switch via RCA, channel control via fader, , gain control, source selector, CUE switch
Microphone channel: 2 x mono via Combination socket (XLR/jack), channel control via rotary dial, 3-band tone control EQ, ON AIR switch, talkover switch
Master output: 2 x stereo via XLR or RCA, channel control via rotary dial, 3-band tone control EQ
Rec. output: 2 x stereo via RCA, NO MIC switch
Headphones output: 1 x stereo via jack, channel control via rotary dial, cue mix split function
Booth output: 1 x mono + stereo via RCA, channel control via rotary dial
Input channel: 1 x stereo via RCA, channel control via rotary dial
Housing design: (19") 48.3 cm rack installation 2 U
Dimensions: Width: 48.3 cm
Depth: 14.8 cm
Height: 8.9 cm
Weight: 3.10 kg

Technical specifications

Brand: OMNITRONIC
SKU: STE-10007103
EAN: 4026397714333
Weight: 3.46 kg
