OMNITRONIC ODX-215T Installation Speaker 100V white
1
of
5
Loading...
€852,95
Unit price
/
Not available
Secure checkout
Description
Description
Weather-proof 15" wall speaker (IP56) with mount, 400 W RMS
- 2-way coaxial system with 38 cm woofer (15") and 3.6 cm tweeter (1.4")
- Durable plastic cabinet with metal grille
- Power selector switch with 8 ohms operating position
- Screw terminals for parallel connection
- With mounting bracket
- Suitable for outdoor use IP56
- For application areas such as: Installation; sports centres/gyms; multi-purpose hall
Scope of delivery
- 1 x top
- 1 x mounting bracket
- 1 x user manual
- 6 x screw
- 1 x safety eyelet
- 1 x lid
- 8 x washer
| IP classification: | IP56 |
| Power: | Program: 800W Rated: 400W RMS |
| Frequency range: | 50 - 18000 Hz |
| Sensitivity: | 103 dB (1W/1m) |
| Max. SPL: | 129 dB |
| Dispersion angle: | 80° x 80° |
| Impedance: | 8 ohms; public address systems 100V |
| Attachment system: | Mounting bracket |
| Power tapping: | 75W; 150W; 300W; 400W RMS via selector switch switchable |
| Connections: | Input: speaker via screw terminal |
| Crossover frequency: | 1500 Hz |
| Speaker: | 1 x woofer 15" Voice coil lows 3" 1 x compression tweeter highs 1.4" Voice coil compression tweeter highs 3" |
| Type of speaker: | On ceiling/on wall speaker |
| Color: | White |
| Dimensions: | Width: 46.8 cm Depth: 59.5 cm Height: 50 cm |
| Weight: | 30.55 kg |
Technical specifications
Technical specifications
