Palmer PAN 04 - DI box, 2-channel, passive
€159,95
Unit price
/
Not available
Description
Description
PAN-04 consists of a chassis containing the equivalent of two PAN-01 units, making it a passive 2-channel DI box. This “stereo” configuration makes it ideally suited for use with certain keyboards and devices that have multiple outputs. Jack input with parallel “THRU” output, transformer-balanced XLR output. Attenuatable input sensitivity, can handle both line-level and speaker-level signals.
Technical specifications
Technical specifications
| Product type | DI boxes |
| Type | passive |
| Channels | 2 |
| Inputs | 2 |
| Input connectors | 6.3 mm jack |
| Max. input level | + 54 dBu |
| Input impedance | 60 k Ohm(s) |
| Input pad | 0 / -30 dB |
| Number of outputs | 2 |
| THRU outputs/channel | 1 |
| Output connectors | 6.3 mm jack |
| Output connectors | XLR |
| Max. output level | + 4 dBu |
| Output impedance | 600 Ohm(s) |
| Frequency response | 10 - 40.000 |
| Transformer balanced | Yes |
| Ratio | 10 : 1 |
| Controls | attenuation |
| Controls | ground lift |
| Cabinet material | sheet steel |
| Cabinet surface | Powder coated |
| Width | 110 mm |
| Depth | 110 mm |
| Height | 45 mm |
| Weight | 0,419 kg |
