Palmer WT PB 40 RK - Power supply unit with 8 outputs for rack mounting
Description
Description
Working with effects units and patchbays in the studio opens up creative possibilities for finding new sounds. If only it weren’t for the hassle of power supplies and the accompanying cable clutter.
That’s exactly why Palmer® offers the Powerbar WT PB 40 RK, which you can mount in a 19" rack and always have a 9V DC output within reach.
The rack-mount power supply helps you keep your studio desk tidy and your signal chain stable. Eight separately isolated centre-negative outputs ensure that digital noise doesn’t creep into your recordings. Two of these individually isolated outputs can be switched to either 9, 12 or 18 volts for added flexibility.
Palmer® WT PB 40 RK simplifies creative work with your effects units and helps keep your studio desk or live rack organised.
Technical specifications
Technical specifications
- Compact universal power supply for 19" rack mounting
- Eight separately isolated centre-negative outputs
- Two outputs switchable to 9, 12 or 18 V
- Total current 2,000 mA
- Secure operation by protecting outputs against short circuts and overload
- Integrated LED power and function indicators
| Product type | Power Supplies |
| Type | 8-channel |
| Mains connector | Plug-in power supply |
| Input voltage | 100 - 250 V |
| Outputs | 8 |
| Output connectors | 2.1 x 5.5 mm |
| Material | Aluminium |
| Surface | Powder coated |
| Surface | anodized |
| Output voltage | 12 V |
| Output voltage | 18 V |
| Output voltage | 9 V |
| Max. output current | 2 A |
| Isolated outputs | Yes |
| Polarity | Center negative |
| Cord length | 150 + 150 cm |
| Indicators | Power |
| Controls | Output voltage selector |
| Width | 482 mm |
| Width | 19 " |
| Depth | 50 mm |
| Height | 26 mm |
| Height | 1/2 U |
| Weight | 0,71 kg |
| Accessories (included) | Power supply |
